Pekka Buttler, 06/2025
Specifications
The table below summarizes the lens’ key specifications:
| Brand: | Fuji Photo Film | Lens name | EBC X-Fujinon•W 1:3.5 f=28mm DM |
| Focal length 1 | 28 mm | Angle-of-view 2 | 75,4 ° |
| Maximum Aperture | f/3.5 | In Production | 1979-1985 |
| Lens mount | Fujica X | Subfamily (if applicable) | –– |
| Length 3 | 42,3 mm | Diameter 4 | 61,0 mm |
| Filter ring diameter | 49 mm | Weight | 159 grams |
| Lens element count | 5 | Lens group count | 5 |
| Aperture blades (S/R/C) 5 | 5 S | Focus throw | ≈120 ° |
| Minimum focusing distance (measured) | 31 cm | Maximum magnification (measured) | 1:8,0 |
| Has manual aperture ring | YES | Has Manual focus ring | YES |
| Aperture mechanism type | Automatic | Aperture click stops 6 | 3.5-5.6-8-11-16-22 |
Further notes:
• Fuji offered three 28 mm lenses for the Fujica X system:
• This X-Fujinon 28 mm f/3.5 introduced in 1979 together with the new Fujica X system
• An X-Fujinar7 28 mm f/2.8 introduced 1981
• An X-Fujinon 28 mm f/1.9 introduced in 1982
• Importantly, the X-Fujinon 28/3.5 (this lens) is significantly different from the Fujinon (M42) 28 mm f/3.5 lens that preceded it. This later lens is a modern 5 elements in 5 groups design, while the predecessor lens was a 7 elements in 7 groups design.
• The front of the lens (filter thread included) do not rotate on focusing.
• The lens lengthens marginally (3,1 mm) when focusing to MFD.
• Besides aperture ring and focus ring, this lens has a button to control the aperture ring’s auto setting (indicated by the yellow diamond). To enter or exit the auto setting, that button has to be pressed.
• The ‘DM’ in the lens’ name stands for “Dial Mode” and means that the lens can be used (on a Fujica X body) in program and shutter priority mode, once the aperture ring’s auto setting is engaged.
• The ‘EBC’ in the lens’ name is short for “Electron Beam Coating” which is what Fuji called its proprietary coating technology8
History
Fuji Photo Film (nowadays: Fujifilm) was among the last major manufacturers to abandon the m42 thread mount for a proprietary lens mount. The Fujica STX-1 camera (introduced 1979) introduced a new lens mount (typically referred to as the Fujica X mount, not to be mistaken for the modern FujiX mount) and a series of new lenses. Many (if not most) of the lenses initially introduced for the Fujica X -mount were simply old (and venerable) Fuji Photo Film designs from the M42 era crammed into a new housing with a new mount.
Fuji has long been known for its high quality lenses – both in SLR’s compacts and medium and large format lenses – and it would have been interesting to see what Fuji Photo Film’s lineup of Fujica X lenses would have developed into. Alas, in the mid-1980s, Fuji Photo Film decided to withdraw from SLR manufacture and focused instead on both compacts and larger film formats. Whether that withdrawal was caused by disappointing sales of the Fujica X line, or due to the advent of autofocus SLR’s, I can only speculate.
Adapting
The only cameras able to natively mount Fujica X lenses are the Fujica STX and AX lines of manual focus, film SLRs. Should you want to use this lens on film, you can count yourself lucky that the AX and STX lines of Fujica’s generally seem to have well designed and manufactured, hence making compatible film bodies readily available for a pittance.
Adapting this lens to a mirrorless, full-frame digital camera is a breeze thanks to the lens having full manual controls (aperture ring, focus ring). However, due to the method of aperture control used the Fujica X lenses, the adapter will need a control ring to allow stopping down the lens (and you will need to remember to engage that ring). However, thanks to the relative scarcity of Fujica X lenses (caused, in part, by the shortish production run), Fujica X adapters are not quite as readily available as for more common, film-era mounts. Hence, while regular adapters are not difficult to come by, specialised adapters (such as speed boosters or tilt/shift adapters) are not easy to obtain.
Due to the shortish flange focal distance used by the Fujica X mount (43,5 mm), adapting this lens to dSLR/SLR mounts is not as problem-free, and – to retain anything near infinity focus – the adapter will necessitate corrective optics. Even so, adapters to many dSLR mounts are available.
Footnotes
- Focal length is (unless stated otherwise) given in absolute terms, and not in Full-frame equivalent. For an understanding of whether the lens is wide/tele, see ‘Angle-of-view’. ↩︎
- Picture angle is given in degrees and concerns the diagonal picture angle. Rule of thumb:
> 90 ° ==> Ultra-wide-angle
70–90 ° ==> Wide-angle
50–70 ° ==> Moderate wide-angle
40–50 ° ==> ‘Standard’ or ‘normal’ lens
20–40 ° ==> Short tele lens
10-20 ° ==> Tele lens
5-10 ° ==> Long tele lens
< 5 ° ==> Ultra-tele lens ↩︎ - Length is given from the mount flange to the front of lens at infinity ↩︎
- Diameter excludes protrusions such as rabbit ears or stop-down levers ↩︎
- S=straight; R=rounded; C=(almost)circular at all apertures. ↩︎
- Numbers equal aperture values on aperture ring; • intermediate click; – no intermediate click.a ↩︎
- This lens was not of Fuji’s own making and was instead a Nittoh Kogaku product that was also sold branded as X-Kominar 28/2.8 ↩︎
- Much Like Canon called its proprietary coating technology ‘Super Spectra Coating’ or Carl Zeiss branded its form of coating magic ‘T*’ ↩︎
