Data sheet: Meyer-Optik Görlitz Oreston (50 mm f/1.8)

Pekka Buttler, 08/2022 (Updated 01/2024)

Specifications

The table below summarizes the lens’ key specifications:

Brand:	Meyer-Optik Görlitz	Lens name	Oreston 1.8/50
Focal length(s) 1	50 mm	Angle-of-view 2	46 °
Maximum Aperture	f/1.8	In Production	1965–1970
Lens mount (this lens)	M42	Other lens mounts	Exakta RTL1000
Length 3	39,7 mm	Diameter 4	63,2 mm
Filter ring diameter	49 mm	Weight	219 grams
Lens element count	6	Lens group count	4
Aperture blades (S/R/C) 5	6 S	Focus throw	310 °
Minimum focusing distance	33 cms	Maximum magnification	1:4,4
Has manual aperture ring	YES	Has Manual focus ring	YES
Aperture mechanism type	Automatic	Aperture click stops 6	1.8-2•2.8•4•5.6•8•11-16

Further notes:
• The Oreston is an Automatic-only lens (no manual aperture mode), but it offers a button for depth-of-field preview.
• The Oreston was designed to act as standard lens on both M42 mount Prakticas and the Exakta RTL1000 camera (which uses a special variant of the Exakta mount)
• The name Oreston identifies the lens as one of MOG’s later series (all MOG lenses post-1963 are named Orest-something).
• The Oreston was replaced in 1970 by the identical-specs Pentacon 50 mm f/1.8, which was manufactured in prodigious numbers and remained in production until the early 1990s (past the demise of the German Democratic Republic).
• While exact numbers are hard to come by, the Oreston and its descendants (various Pentacon 50/1.8 lenses) are likely to be among the most popular lens designs ever (in terms of the number of manufactured copies)
• The Oreston itself was a further development of the Meyer-Optik Domiron. From the beginning the purpose was to develop a bright, affordable standard lens.
• For further notes on Meyer-Optik Görlitz and especially their naming logic, see the JAPB article on MOGnames.
• The East German optics industry did not have a tendency towards producing dedicated macro lenses (the only exception is the late, rare Macro-Praktica 55 mm f/2.8). Instead both MOG as well as Carl Zeiss Jena tended to produce wide and standard lenses with very short minimum focusing distances (while serious macro work was intended to make use of a bellows). To facilitate its 0,33 meter MFD, the Oreston has a significant extension when focusing towards MFD.

History of Meyer-Optik Görlitz

The original Meyer-Optik Görlitz (not the modern company that has taken the classic company’s name) was founded in the town of Görlitz (modern-day Germany) by Hugo Meyer in 1896, and remained in existence until the state-directed merger into VEB Pentacon 1970. Due to its vicinity with the German camera and optics industries in Saxony (Dresden, etc.), Meyer-Optik was from an early stage heavily involved with manufacturing lenses for all kinds of cameras, but the company’s real golden age started with the advent of interchangeable lens cameras, where Meyer-Optik was uniquely placed to offer a cost-effective alternative to premium brands such as Carl Zeiss Jena.

Meyer-Optik was pronouncedly a camera lens manufacturer and never had serious ambitions for pursuing horizontal integration (diversifying into cameras and other photo gear). Instead, MOG pursued a vigorous strategy of seeking economies of scale, combined with never putting too many eggs in any basket – typically Meyer-Optik would choose which designs to put into production based on being able to cover as many platforms/mounts with one basic design. As a result, many early MOG designs were made available for a wide range of camera platforms. Later, as the number of alternative platforms diminished, that strategy had to go in favour of a strong focus on M42 and (to a somewhat lesser extent) Exakta. Even so, throughout the 60s, MOG vigorously pursued innovative designs and could by the end of the decade proudly offer a wide range of high-quality, cost effective designs.

When the lens maker Meyer-Optik was then merged with the camera maker Pentacon, it became obvious that the role the company (and its product portfolio) was intended to play was to aid Pentacon in its designs of gaining a significant global market share in the price-conscious consumer segment (and help bring hard currency to the G.D.R). Instead of focusing on continued optical innovation, the new overlords were more keen on redesigning lenses for greater economy and easier manufacture. As a result, the pace of optical innovation at MOG/Pentacon fell drastically, and very few new designs or significant redesigns were to be forthcoming in the next two decades.

However, the Meyer-Optik Oreston comes from what would later be known as the golden decade of Meyer-Optik. While the names Meyer-Optik and Oreston were soon to disappear from view, the design work done at Meyer-Optik would turn out to have an impactful legacy.

Versions

The Oreston was originally introduced for the M42 mount. Subsequently a version was also manufactured for the Exakta mount, but those remain rarer today.

Going forward from Meyer-Optik to Pentacon, the Oreston was redesigned and re-engineered several times, resulting in a great number of outwardly distinguishable versions. Furthermore, the later Pentacon 50/1.8 would also be offered in Praktica B-mount.

Adapting

n.B! The following applies this lens in M42 mount.

This lens cannot be used natively on any current SLR or dSLRs. To use it in its native environment, you will need an M42-mount film body. Luckily there are a lot of those (especially in M42 mount) available. Because the lens is an Automatic-only lens, the camera must be able to trigger the M42 Automatic lens’ stop-down pin.

Thanks to being a fully manual lens (manual aperture, manual focus), the lens can be adapted to all mirrorless cameras using a suitable adapter. The lens not offering manual aperture mode, the adapter should have a flange for depressing the M42 lens stop down pin. Owing to the popularity of the M42 mount, special adapters (helicoid adapters, tilt/shift adapters) are readily available. Alternatively, one can choose to daisy-chain adapters (e.g. M42->Canon EF; Canon EF –> mirrorless) which also opens up a wide range of speed boosters .

Using m42 lenses on dSLRs can also be an easy option, depending on which dSLR.
• Canon EF has the shortest flange focal distance among full-frame dSLR’s and Canon’s wide range of dSLRs are able to mount M42 lenses perfectly using a simple adapter ring.
• Minolta / Sony A and Pentax K dSLRs are likewise able to mount M42 lenses using a simple adapter ring.
• Nikon F dSLRs have a long flange focal distance, meaning that mounting M42 lenses needs an adapter that uses corrective optics to allow anything close to infinity focus.

Footnotes

1. Focal length is (unless stated otherwise) given in absolute terms, and not in Full-frame equivalent. For an understanding of whether the lens is wide/tele, see ‘Angle-of-view’. ↩︎
2. Picture angle is given in degrees (based on manufacturers’ specs) and concerns the diagonal picture angle. Rule of thumb:
   > 90 ° ==> Ultra-wide-angle
   70–90 ° ==> Wide-angle
   50–70 ° ==> Moderate wide-angle
   40–50 ° ==> ‘Standard’ or ‘normal’ lens
   20–40 ° ==> Short tele lens
   10-20 ° ==> Tele lens
   5-10 ° ==> Long tele lens
   < 5 ° ==> Ultra-tele lens ↩︎
3. Length is given from the mount flange to the front of lens at infinity. ↩︎
4. Diameter excludes protrusions such as rabbit ears or stop-down levers. ↩︎
5. S=straight; R=rounded; C=(almost)circular at all apertures. ↩︎
6. Numbers equal aperture values on aperture ring; • intermediate click; – no intermediate click. ↩︎
