Data sheet: Carl Zeiss Super-Dynarex 200 mm f/4

Pekka Buttler, 01/2023

My (outwardly) rather dirty sample of the Carl Zeiss Tessar 50 mm f/2.8 (Icarex mount)

Specifications

The table below summarizes the lens’ key specifications (Measurements based on pictured sample):

Brand:Carl ZeissLens nameSuper-Dynarex 4/200
Focal length(s)1200 mmAngle-of-view212,3 °
Maximum Aperturef/4In Production1968–1972
Lens mountsIcarex BMSubfamily (if applicable)––
Length3147 mmDiameter485,7 mm
Filter ring diameter77 mmWeight693 grams
Lens element count5Lens group count4
Aperture blades (S/R/C)55 SFocus throw210 °
Minimum focusing distance3 mMaximum magnification1:12,9
Has manual aperture ringYESHas Manual focus ringYES

Further notes:
• This lens is a further development of the Voigtländer Super-Dynarex 200/4 introduced in 1959 for the Voigtländer Bessamatic leaf shutter camera.
• Compared to all modern (and most contemporary) 200 mm f/4 designs, this lens uses a large diameter front element. While this does make the lens rather bulky, it does carry the advantage of producing rather negligible wide-open vignetting.
• Alike all lenses offered for the Icarex line of cameras, its aperture ring is without click-stops.
• Unlike all shorter (focal length) Zeiss Icarex lenses, this lens has a traditional filter thread, but it’s diameter is a (for the legacy-age) whopping 77 mm.
• Unlike most other Zeiss Icarex lenses, this lens was never produced in m42 mount.
• The lens includes a telescoping, built-in lens hood, that even uses a magnetic design to secure the hood in resting/extended positions.
